5MP 5in1 4CH AHD/CVI/TVI/analog DVR Security CCTV video recorder P2P 1080P NVR VGA HDMI for HD AHD/XM ip camera xmeye

$139.99

Clear
SKU: N/A Category:

Description

录相机



Package Included



  • 1 X 4CH 5MP AHD DVR NVR HVR 5 in 1 Digital Video Recorder

  • 1 x 12V 2A power adapter for DVR

  • 1 X USB Mouse for DVR

  • 1 X Software CD for DVR

  • 1 X Remote Control for DVR

  • 1TB Hard Disk Included !!!!



5-IN-1-4MP-AHD-DVR-NVR-HVR-CCTV-4Ch-8Ch-Hybrid-Security-DVR-Recorder-Camera



Overview



AHCVBIVN CCTV Security – HD CCTV Camera Security System, A guaranteed and reliable Security Solution for your Home and Business! 720P/960P/1080P/2MP/3MP/4MP/ 5MP High Definition and Video at day and night. Email alerts and Motion detection, IP66! Waterproof and universal for Outdoor/Indoor, free app for P2P Cloud function and storage, support  android, iPhone , ipad,PC,CMS etc.



4CH 5MP AHD DVR Recorder

Strong Network Server;
With P2P Cloud Function;
support USB ,Mouse,backup;
Support Android,iphone,ipad,pc,cms view;
Support VGA output&HDMI output;
Support Alarm input ,Alarm output;
Record Resolution: 5.0MP;
With H.265 High efficiency Video Compression;
Auto White Balance,Auto Gain control,back light comp;
HDD Interface:SATA,Support between 500GB and 8TB;
Multi-language menus option up to 28 kinds of language;
*Support 5.0MP cameras input and HDMI &VGA Output ;
*P2P cloud service for Android/iOS mobile devices remote view anywhere anytime;
*Motion detection recording. The NVR will be triggered to record when detect something moving. NO trigger, no record, more intelligent and space-saving;
*Email alert and alarm notification. When motion detection is triggered, the NVR will automatically send out buzzer sound and alarm notifications to your email, including snapshot on the spot;
*Multiple ways to access on the PC, phone and pad, can be viewed by PC client, Phone APP and IE ,Chrome,Firefox,Safari browser;
*Support 3.5 inch SATA port hard drive, capacity about 500G/1T/2T/3T/4TB/5TB/6TB/7TB/8TB, and less than 500G is not supported.
HD CCTV AHD DVR Digtial Video Recorder,Support all 1.0mp&2.0mp&3.0mp&4.0mp&5mp Camera



Advanced H.265 Video Compression



Why choose H.265

H.265vsH.264





disk H265

HD CCTV NVR Specifications



1. H.265 4CH 5MP DVR Specifications



System

Main processor: Embedded processor

Operating system: Embedded Linux

Video compression:H.265

System resource:Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up

Interface

Operation interface:16bit real color GUI interface support

Preview :  1/4

Video

Video standard :PAL; NTSC

Image encode:H.265

Monitor quality: VGA,HDMI:High definition

Analog input :4CH*5MP

Hybird input: 2CH*1080P(Analog)+2CH*1080P(Network)

Network input:4CH*5MP / 16CH*1080P

Motion detection:Support

Email Alert : Support

Audio

Audio compression :G.711A

Intercom : Yes

Record&Playback

Record mode:manual>alarm>motion detection>timing

Local playback:5MP

Video search:Time, date, event, channel search

Storage&Back up

Video storage : Local HDD ,Network

Back up mode: Network backup, USB portable,HDD,USB imprint,SATA imprint

Interface

Video input:4CH BNC

Video output : 1ch VGA,1ch HDMI HD output

Loop output : N/A

Audio I/O :1CH Output/1CH input

Alarm I/O:No

Network port:1* POE RJ45 1000M self-adaptive Ethernet port;

USB port : 2* USB 2.0

HDD port :1 SATA ports,max support 8TB(HDD is optional)

Other

Power   :DC 12V

ONVIF :Support

USB Mouse:included

Remote Control : included

Temperature : -20℃+50℃

Humidity : -10%-90%

Dimension : L255mm* W225mm* H45mm

Weight :1.5KG

DVR Language

Russian, English, Finnish, French, German, Greek, Italian, Japanese, Poland, Protugal, Spanish, Thai, Turkey Romanian, Slovakia, Czech, Arabic, Swedish and so on





DVR背面展示4CH

2. H.265 5MP  HD Display

High-Definition interface output,Suport for online playback,Mobile remote,Multi-window display with 5.0MP Resolution.The angle will be more larger,and the image will be more clearer.

H1136987119154867a2de134b568639f1S

3. AHD DVR NVR HVR 5IN 1



You can freely enjoy five connection modes with this one multi-function digital video recorder.AHD(Analog High Definition)is new advanced technology on home security with 5 recordering modes.for your option:Analog / Network / TVI / CVI / AHD+Network. You can get HD quality video in each mode.

H1c649a82e08f41d38cd17e90a907ec61y





4. Multiple Viewing Options



View on HDMI Monitor

Easily display video through the HDMI port of your computer monitor to take full advantage of the security system’s

clarity. (HD Cable Not Included)

View on TV or PC Monitor

For added convenience, the DVR also comes with VGA and BNC connections for standard resolution viewing options.

VGA or BNC to RCA cable is not included.




f34

5. Remote access anywhere,anytime



View live video of the system from anywhere and anytime via you smarphone, table or PC with advanced P2P technology, you are able to remote access your system in minutes or less, no portforwarding needed, remote access has never been so easy!!!



未标题-1

6. Instant email alert

Can set up the area you want to control,When it is triggered,it will send message to your email ,You can get the first hand information ,no matter when and where you are .



报警


Smart Playback

You can easy find the video footage you’d like to playback,Smart playback available with customizable searching area, playback time is greatly reduced by speeding through unimportant videos.


HTB1VZCFX1bviK0jSZFNq6yApXXaw



Easy remote view setting



Easy setting , just 4 steps for mobile phone viewing,View live video of the system from anywhere and anytime via you smarphone, table or PC with advanced P2P technology, you are able to remote access your system in minutes or less, no portforwarding needed, remote access has never been so easy!!!

H233a7d6a65304ffd944ffe76e93069ddy

HTB1vrhReqLN8KJjSZFmq6AQ6XXaP

Easy p2p cloud remote view



If you want to remote view thourh Internet

Please login your Google or IE or Firefox browser

Then input Website of P2P Cloud: www.xmeye.net

Input your P2P ID, and your password, login in.

(If you want to remote visit the DVR through P2P, At first, you need open the “www.xmeye.net”, If your computer can’t open this website, please install all the Plug-ins in your computer, Otherwise, you will not be able to remotely access this DVR, Please note).

HTB1j..Sob_I8KJjy1Xaq6zsxpXaY



HTB1TUi3olDH8KJjSszcq6zDTFXaI



CMS For Local Review



Default Username of CMS:Super  Password: null(empty)



HTB1R3FeaSf2gK0jSZFPq6xsopXaG



Plug and play ,Easy to use!!!

H3599fc59ec9f4721895dcce0cb8c141cH

Application Scenarios

VCGF
